Lift-N-Tow Forklift Tow Hitch Attachment
- Universal ‘slip on forks’ style
- Easily swap between ball, pintle and combination hitches
- Rugged heavy-duty construction for increased durability and long life
- Includes convenient tool tray on 1390B
Safely lift, load & tow with your forklift
Don’t risk an OSHA citation. Star Industries Lift-N-Tow is the safe and easy way to lift, load and tow with your forklift. Simply slip over the forks and swap between ball, pintle and combination hitches to lift and tow all types of loads weighing up to a massive 10,000 lbs for the standard Lift-N-Tow, a massive 16,000 lbs towing weight for the Super Duty Lift-N-Tow and 30,000 lb with the Navy Lift-N-Tow.Hitches
A hitch is required for the Lift n Tow. Hitches sold separately - see specifications tab for more details.
Adapter with 2" Ball Model 1391
Adapter with Pintle Hitch Model 1392/1394PH
Adapter with Combo Hitch Model 1393/1394CH
Lift-N-Tow
| Model | Accepts forks | Max Lift Capacity on Swivel Hook | Max Lift Capacity on Receiver Jib | Max Gross Towing Weight | Weight (w/o Hitch Adaptor) | Fork Size |
Center-to-center of Fork Opening |
Pocket Ends | |
|---|---|---|---|---|---|---|---|---|---|
| Lift-N-Tow | 1390B | 6” w x 2 ¾” thick |
4,000 lbs | 2,000 lbs | 10,000 lbs | 220 lbs | 48” long x 6 ¾ x 3” ID | 13 ¼” | Open |
| Super Duty Lift-N-Tow | 1395B | 8” w x 2 ¾” thick |
10,000 lbs | 3,000 lbs | 16,000 lbs | 400 lbs | 48” long x 8 ¾ x 3” ID | 34 ¾” | Open |
| Navy Lift-N-Tow | 1396C | 8″ w x 2 ¾” thick |
12,000 lb | 6,000 lbs | 30,000 lbs | 505 lbs | 48” long x 8 ¾ x 3” ID |
34 ¾” | Open |
Lift-N-Tow & Hitches sold separately.
Hitch Adapters
| Model | For Lift-N-Tow Model | Style of Adapter | Max Vertical Lift | Max Gross Towing Weight | Horizontal Center of Gravity | Weight (Adapter Only) |
|---|---|---|---|---|---|---|
| 1391 |
1390B |
2” Ball | 600 lbs | 10,000 lbs | 28” |
10 lbs |
| 1392 |
1390B |
Pintle | 2,000 lbs | 10,000 lbs | 29” |
15 lbs |
| 1393 |
1390B |
Combo | 2,000 lbs | 10,000 lbs | 30” |
20 lbs |
| 1394PH |
1395B |
Pintle | 3,000 lbs | 16,000 lbs | 29” |
21 lbs |
| 1394CH |
1395B |
Combo | 3,000 lbs | 16,000 lbs | 30” |
25 lbs |
Note: Pintle Hitch included with model 1396C Navy Lift-N-Tow
Danger: Do NOT use without installing retaining pins behind the heel of each fork and securing with hairpins or cotter pins. Safety chain(s) must also be used. Wrap chain around a strong part of the fork carriage and secure with locking grab hook. Operating manual/safety information available online and by calling 1-800-541-1797.
Lift Loads Safely with a Forklift Tow Hitch Attachment
Whether you manage a warehouse, oversee a construction project, or run a busy rental equipment yard, a forklift tow hitch is the perfect attachment for lifting, loading, and towing.
What Is a Forklift Tow Hitch Attachment?
A forklift towing attachment is a device that mounts onto the forks or carriage of a forklift, allowing it to tow trailers, carts, or other equipment. It typically consists of a sturdy metal frame with a hitch receiver designed to connect securely to the towed load. Some models are adjustable to accommodate different hitch sizes, while others are built for specific applications. The attachment is easy to install and remove, making it a convenient addition to any forklift fleet.
Key Features of a Forklift Tow Attachment
Safe and Compliant
Don’t risk an OSHA citation. A forklift tow hitch is a safe and easy way to lift, load, and tow your forklift. Depending on the model, you can swap between ball, pintle, and combination hitches to lift and haul loads weighing up to 30,000 lbs.
Rugged Construction
Forklift tow hitches are constructed from quality materials, such as steel, to withstand heavy loads and harsh working conditions.
Ease of Use
These hitches are designed for quick and easy installation. Most models require no special tools or modifications to the forklift, allowing operators to seamlessly switch between towing and standard forklift operations. Simply slip over the forks and secure them.
Safety
Towing heavy loads manually or with improvised methods can be hazardous. A forklift tow hitch provides a secure and stable connection, minimizing the risk of load shifts, tip-overs, or accidents. They also have safety features such as locking mechanisms and reinforced frames to prevent accidents and ensure secure towing.
Benefits of Using a Forklift Towing Attachment
By adding towing capabilities to an existing forklift, businesses can avoid the expense of purchasing dedicated tow vehicles. This cost-saving benefit makes this attachment an attractive investment for companies looking to maximize their equipment’s potential. Other benefits include:
Improved Efficiency
A forklift tow hitch attachment streamlines material handling processes, allowing operators to transport multiple loads simultaneously. Instead of making multiple trips to move pallets and equipment, a forklift can tow a trailer loaded with materials, reducing downtime and increasing productivity.
Enhanced Safety
Towing heavy loads manually or with improvised methods can be hazardous. A tow hitch provides a secure and stable connection, minimizing the risk of load shifts, tip-overs, or accidents. Safety is paramount in busy work environments where workers and equipment constantly move.
Space Optimization
Space is often scarce in crowded warehouses or construction sites. A hitch allows operators to move large or bulky items without cluttering walkways or work areas, improving overall site organization.
Reduced Labor Costs
This attachment reduces the need for additional manpower by enabling a single operator to handle lifting and towing tasks. This efficiency translates into lower labor costs and faster project completion times.
Applications Across Industries
The forklift tow hitch attachment is a game-changer for businesses looking to enhance their material handling capabilities. Its durability, versatility, and safety features make it an invaluable tool in industries ranging from warehousing and manufacturing to construction and agriculture.
Warehousing, Logistics, and Distribution
Tow hitches move loaded carts, pallet jacks, and trailers between storage areas and loading docks. This capability speeds up order fulfillment and reduces the time spent on material transport.
Manufacturing
Manufacturing facilities often need to move heavy machinery, raw materials, and finished products across the plant floor. A tow hitch simplifies these tasks, ensuring smooth operations and minimizing downtime.
Construction
Construction sites are dynamic environments where equipment and materials must be transported frequently. Forklift tow hitch attachments are ideal for towing trailers loaded with tools, debris, or building supplies, improving site efficiency and safety.
Agriculture
In agricultural settings, itches tow trailers filled with produce, feed, or equipment.
Want to explore more of our forklift attachments? Talk with our team today.
